Alive

The Alive is a cutting-edge Smart Living Station designed to enhance room monitoring.

Equipped with a wide range of sensors, an 8MP super-wide-angle camera, and advanced radar technology, Alive ensures comprehensive coverage and real-time alerts for motion, air quality, and much more.

Footage

Specs

Dimensions & Weight

• Dimensions: L 159 mm x W 159 mm x H 35 mm
• Weight: 430g (without mounting plate)

Operation & Protection

• Operating Temperature: -5°C to +55°C
• Protection Class: IP20

Power

• Input Voltage: 110-230V AC, 5V/3A DC via USB-C
• Backup Battery: 3.6V Li-ion, 6800 mAh capacity
• Battery Life: 4-5 hours of power

Connectivity

• Wi-Fi: 802.11 a/b/g/n/ac, 2.4 GHz and 5 GHz
• LTE: Max Downlink 150 Mbps, Max Uplink 50 Mbps
• Bluetooth: Bluetooth 5.0 for device pairing and control
• NFC: Near Field Communication for easy pairing
• Thread: Supported (with software update)
• Zigbee: Supported (with software update)

Camera

• Resolution: 3280 x 2464 (8.08 MP)
• Lens: Super wide-angle
• Field of View: 180° horizontal, 135° vertical, 200° diagonal
• Infrared: 24 infrared LEDs (850nm) with automatic IR filter for night vision

Motion Detection

• Sensor: 24GHz radar
• Field of View: 121° horizontal, 111° vertical

Environmental Sensors

• Temperature: Combined temperature sensor
• Humidity: Integrated humidity sensor
• VOC: Volatile Organic Compound (VOC) sensor for air quality monitoring
• CO Sensor: Carbon monoxide detection
• LUX Sensor: Ambient light sensor

Audio

• Microphones: 5 integrated microphones for voice detection and sound monitoring
• Speakers: Built-in speakers with 90 dB output for audio feedback

Audio-Visual Feedback

• LEDs: RGB-LEDs for visual feedback
• Speakers: Integrated for audio feedback
